Source DKDP/KD*P with Various Deuteration (90%-99%)

High deuteration ratio (>99.0%)
High homogeneity
Excellent internal quality

High deuteration (> 99.0%)

High EO Coefficient

Good UV transmission

High optical damage threshold

High birefringence

Negative thermal lensing

Top finish quality with high processing precision
Large block for various size and shapes
Very competitive price

Mass production, quick delivery


  Contact Now
Product Details

Characterized by the excelent UV transmission, high damage threshold, and high birefringence, KDP (Potassium Dihydrogen Phosphate)  and KD*P (Potassium Dideuterium Phosphate) are useful commercial NLO materials for doubling, tripling and quadrupling of Nd:YAG laser at room temperature or an elevated temperature. They are also excellent electro-optic (EO) crystals with high electro-optic coefficients, widely used as electro-optical modulators and Pockels cells for Q-switched lasers.

DKDP and KDP are known as analogs, though their properties differ due to DKDP deuteration. The nonlinearity of these crystals is relatively low, but they can be grown in large size.The main drawback is that they are highly hygroscopic, therefore sealed housing and dry operating conditions have to be ensured.

KDP and DKDP crystals have such applications as nonlinear frequency doublers, triplers, and quandruplers of Nd-doped lasers and as Q-switch devices for Ti:Sapphire, Alexandrite, Nd-doped lasers.


WISOPTIC' KDP/KD*P WITH BEST COST PERFORMANCE IN THE WORLD


Deuteration Ratio

> 99.00%

Dimension Tolerance

± 0.1 mm

Angle Tolerance

≤ ± 0.25°

Flatness

< λ/8 @ 632.8 nm

Surface Quality

< 20/10 [S/D] (MIL-PRF-13830B)

Parallelism

< 20”

Perpendicularity

≤ 5'

Chamfer

≤ 0.2mm @ 45°

Transmitted Wavefront Distortion

< λ/8 @ 632.8 nm

Clear Aperture

> 90% of central area

Laser Damage Threshold

> 600 MW for 1064nm, TEM00, 10ns, 10Hz (AR-coated)
> 400 MW for 532nm, TEM00, 10ns, 10Hz (AR-coated)


* Products with special requirement upon request.
