DKDP, KD*P Crystal

Excellent internal quality

High deuteration (> 99.0%)

High EO Coefficient

Good UV transmission

High optical damage threshold

High birefringence

Negative thermal lensing

Top finish quality with high processing precision
Large block for various size and shapes
Very competitive price

Mass production, quick delivery



  Contact Now
Product Details

Potassium Dihydrogen Phosphate (KDP) and Potassium Dideuterium Phosphate (KD*P, DKDP) crystals are

among the most widley used nonlinear crystals. Both of these crystals are routinely used for the doubling, tripling

and quadrupling of Nd:YAG lasers at room temperatures. In addition, their excellent electro-optic coefficients makes them commonly operating as EO modulators, Q-switches and Pockels cells.


Advantages of DKDP / KD*P crystals:

  • Good UV transmission

  • High optical damage threshold

  • High birefringence

  • High nonlinear coefficients


Applications of DKDP / KD*P crystals:

  • SHG with high pulse energy, low repetition rate (<100Hz) Q-switched and mode-locked Nd:YAG

  • THG with high pulse energy Q-switched and mode-locked Nd:YAG via sum frequency generation

  • FHG with high pulse energy Q-switched and mode-locked Nd:YAG

  • EO modulation

  • Q-switching

  • SHG and THG using high power Nd:YAG (1342nm and 1319nm)

  • OPO and OPO applications

  • Can be pumped by a wide range of sources


WISOPTIC' KDP/KD*P WITH BEST COST PERFORMANCE IN THE WORLD


Deuteration Ratio

> 99.00%

Dimension Tolerance

± 0.1 mm

Angle Tolerance

≤ ± 0.25°

Flatness

< λ/8 @ 632.8 nm

Surface Quality

< 20/10 [S/D] (MIL-PRF-13830B)

Parallelism

< 20”

Perpendicularity

≤ 5'

Chamfer

≤ 0.2mm @ 45°

Transmitted Wavefront Distortion

< λ/8 @ 632.8 nm

Clear Aperture

> 90% of central area

Laser Damage Threshold

> 600 MW for 1064nm, TEM00, 10ns, 10Hz (AR-coated)
> 400 MW for 532nm, TEM00, 10ns, 10Hz (AR-coated)

* Products with special requirement upon request.

DKDP, KD*P Crystal.jpg
