Precision UVFS,BK7 Right Angle Prisms

WISOPTIC advantages of right angle prisms

High angle precision (<5 second)

High flatness(<lambda/10)

High angle pyramid tolerance(<5 second)

Sorts of material: BK7 Grade A optical glass, Corning Fused Silica 7980, JGS1 UV Grade Fused Silica, and JGS2 UV Grade Fused Silica

Competitive price and lead time

  Contact Now
Product Details

Right angle prisms are generally used to bend image paths or redirect light at 90°. This produces a left handed image and depending on the orientation of the prism, the image may be inverted or reverted. Right angle prisms can also be used in combination for image/beam displacement.

right angle prism.jpg

The advantages of right angle prisms

The capability of right angle prism to alter the image makes it a staple component in optical systems ranging from high-performance applications in scientific, healthcare and industrial fields, as well as general use optical instruments such as telescopes or binoculars.

Right angle prisms offer a significant advantage compared to typical mirrors because of greater resistance to mechanical load and external stress. This makes them more suitable for applications which operate in demanding conditions, such as vibrations or rapid movements. Prisms provide also enormous improvement in terms of ease of mounting and alignment, which reduces application complexity, cost and time to market.



WISOPTIC Standard Specifications

Right Angle Prism
MaterialBK7 grade A optical glass, etc.
Dimension Tolerance+0.0,-0.2mm
Clear Aperture>80%
Angle Tolerancerefer to the table below
Flatnessλ/2@633nm
Surface Quality60/40 scratch/dig
Bevel0.2mm to 0.5mm
CoatingUncoated




Size(mm)3 min.Deviation1 min.Deviation30 Sec.Deviation
A,B,CPart NoPart NoPart No
A=B=C=2.0RAP1101RAP1201RAP1301
A=B=C=3.2RAP1102RAP1202RAP1302
A=B=C=5.0RAP1103RAP1203RAP1303
A=B=C=10.0RAP1104RAP1204RAP1304
A=B=C=12.7RAP1105RAP1205RAP1305
A=B=C=15.0RAP1106RAP1206RAP1306
A=B=C=20.0RAP1107RAP1207RAP1307
A=B=C=25.4RAP1108RAP1208RAP1308
A=B=C=30.0RAP1109RAP1209RAP1309


Precision UVFS,BK7 Right Angle Prisms.jpg


Precision UVFS,BK7 Right Angle Prisms.jpg


Precision UVFS,BK7 Right Angle Prisms.jpg
