Optical Lenses

Various of shapes: spherical, achromatic, aspheric, Powell, and cylindrical lenses

Enough choice of substrates: N-BK7, N-SF6, UV fused silica, calcium fluoride, magnesium fluoride, zinc selenide, germanium, and silicon.

Precisely processing and coating

Very competitive price and lead time


  Contact Now
Product Details

Optical Lenses are designed to focus or diverge light and for imaging or alignment in an optical system. Optical Lenses, which may consist of a single or multiple elements, have a variety of applications. Lens forms can be divided into simple lenses (which include plano-convex lens, plano-concave lens, double-convex lens, double-concave lens, cylinder lens, drum lens, spherical lens in different shapes), achromatic lenses compound lens and multiple types. When light passes through a lens, it is refracted changing the direction of the output light by the lens profile or the lens substrate.

Applications:

  • Magnification

  • Correction of optical aberrations

  • Use as a firestarter (burning-glasses)

  • Image focusing

  • Image projection


Optical Lenses.jpg



Medium Precision

High Precision

Aperture

5~200 mm

20~1000 mm

Surface Quality [S/D]

< 40/20 [S/D]

< 40/20 [S/D]

Surface Irregularity

PV< 0.5~5 µm

RMS< λ/50 @ 632.8 nm

Aspheric Surface Type

  Quadric, High order

Quadric, High order

Manufacture Capability

300 pcs/month

20 pcs/year


Optical Lenses.jpg


Optical Lenses.jpg
