Customized Periodically Poled MgO:LN Crystal

  • Multi-band AR coated

  • Flatness <λ/4@633nm

  • Parallel to ±5 minutes

  • Better than 70:30 mark-to-space ratio

  • Polished to 20-10 scratch-dig

  • Fewer than two 100μm edge chips per facet

  • Custom design

  • Quick delivery

  • Competitive price


  Contact Now
Product Details

Readily available stock of periodically poled MgO:LN crystals can be provided on short timescales to rapidly meet your application needs, providing the capability to efficiently generate laser light in a wide range of wavelengths.

MgO:PPLN SHG crystals are available for a wide range of common pump laser wavelengths from 976 nm to 2100 nm, allowing generation of light between 488nm and 1050nm.

MgO:PPLN OPO are available for 515nm and 1064nm pump sources, allowing continuous wavelength generation in a selection of ranges in the visible and IR.

MgO: PPLN DFG Crystals are available for various combinations of pump sources, for generation wavelengths between 2 and 5.5 um.

MgO:PPLN SFG Crystals are available for various combinations of pump sources, for generation of wavelengths between 500 and 700nm.

Wisoptic provides design for researchers who need up to 1 – 2W of output power through a reliable method of SHG generation.


Customized Periodically Poled MgO:LN Crystal .jpg

Customized Periodically Poled MgO:LN Crystal .jpg


Customized Periodically Poled MgO:LN Crystal .jpg


Customized Periodically Poled MgO:LN Crystal .jpg
